HPU Vacuum Unit

Reliable Vacuum supply for modern dairy farming

The Milkline HPU Vacuum Unit provides a consistent and reliable vacuum supply, a core requirement for any dairy farming operation. Leveraging 50 years of expertise in dairy technology, Milkline offers systems that integrate seamlessly with milking equipment and enhance milking parlor design. Compact, versatile, and easy to install, the HPU Vacuum Unit is suitable for any both conventional milking parlours.

3D Catalog

Features

The HPU Vacuum Unit has a compact design that fits easily into any milking parlor, optimizing space for your farm needs.

Designed for straightforward installation, the HPU reduces downtime and integrates smoothly with existing milking systems

Milkline offers multiple configurations and accessories, including hot-dip galvanised vacuum tanks, cyclone oil recirculation systems, gear reduction units, and the VARIOSPEED VCU drive. This versatility ensures compatibility with various milking systems setups.

The HPU vane vacuum units use a v-belt transmission and squared pumps to optimize heat dispersion, delivering long-lasting, reliable performance for medium and large herds.

The three-way capillary oiler provides precise oil dosing with no waste, protecting your vacuum system and ensuring consistent vacuum levels.

The optional VARIOSPEED VCU allows precise control of the vacuum unit, maximizing efficiency and adaptability for modern dairy technology.

Technical specifications of HPU Vacuum Unit for dairy farming

  • Pump Type: Belt-driven, oil-lubricated vane vacuum pump
  • Airflow Capacity [at 50kPa]: 330 – 3,000 l/min
  • RPM: 970 – 1,500
  • Motor Power: 0.75 – 7.5 kW
  • Available Configurations: On plate, with or without vacuum tank
  • Optional Accessories:
    • Hot-dip galvanised vacuum tank (22 – 100 l)
    • Cyclone oil recirculation system
    • Gear reduction unit
    • Milkline VARIOSPEED DVC
    Hot-dip galvanised vacuum tank (22 – 100 l)Cyclone oil recirculation systemGear reduction unitMilkline VARIOSPEED DVC
